Jensen Tornado Stealth 100 Large Cabs - Supercab IR Library
The official Jensen IR library based on the “Tornado Stealth 100” N12/100 TRS 100W Neodymium speaker

Jensen Tornado Stealth 100 Large Cabs - Supercab IR Library (864 IRS)
This is a systematic capture of a Jensen Tornado 100, from the Jet series, installed in three different enclosures:
- a 2x12" Open Back cabinet
- a 2x12" Closed Back cabinet
- a 4x12" Closed Back cabinet
for a total of 864 IRs, developed in conjunction with a Jensen Speakers product specialist, in order to recreate the most authentic playing experience, as if you were playing an original speaker.
The Tornado 100 is the first Jensen Jet speaker loaded with the 2nd Generation Neodymium magnet design. The Tornado 100 is an evenly balanced speaker, clear, smooth and well defined, with a solid, powerful bass range. Excellent dynamic range and headroom make the Tornado 100 eminently versatile, from clean to crunch and lead tones, suiting to a wide range of musical genres, up to the highest gain application. The well-defined attack keeps the presence of the tone in the mix, blending in with the complex midrange, typical of the large 2x12 and 4x12 cabinets, and the solid bass response.
DISCOVER THE ENTIRE COLLECTION
The series of the official Jensen® IR Libraries is growing every day!
Any single library in the collection is created after an extensive sampling and editing work in conjunction with Jensen Speakers product specialists, seeking for perfection in every capturing step.
GET MORE, SAVE MORE
Bundles of 3 and 10 libraries with increasing discounts are available

Made for the supercabinet
The library is created for the TH-U Supercabinet, which allows to:
- graphically browse the IRs in the library
- blend them together
- craft new cabinet tones with the unique Multiband mode
- use the IR in the software
- export the IRs in .wav, compatible with the software IR loaders and all the major hardware modelers
Specifications
The microphones used during the capturing session are:
- AKG C12
- AKG C414
- AKG C414 XLS
- Audio Technica AT4033
- Coles 4038
- Electro Voice RE16
- Groove Tubes MD1
- Neumann KM84
- Neumann U47
- Neumann U87
- RODE NT1
- Royer R121
- Sennheiser E609
- Sennheiser MD421
- Shure B52
- Shure SM57
- Shure SM58
- Shure SM81
Every microphone has been moved to 4 different horizontal position (Cap, Cap Edge, Cone and Cone Edge), two distances and two angles, for a total of 16 IRs each.
All the measurement set has been repeated for each one of the cabinet in the library.
All IRs have been phase aligned and they can be blended without phase cancellations.
